All images and diagrams (Draw.io) crashing after change server ip address #1849

New Issue

OVERLORD · 2026-02-05T02:02:38+03:00

OVERLORD commented

2026-02-05 02:02:38 +03:00

Originally created by @1vicente on GitHub (Sep 14, 2020).

Describe the bug
In homolog enviroment when the server change ip address, all images and diagrams (Draw.io) are crashing.

Verifying I found some possible reason: - images link not change with actual server ip address.

But is necessary investigate a reason of diagrams (draw.io) are crashing too.

Steps To Reproduce
Steps to reproduce the behavior:

Create a page;
Put in an image;
Force to change server IP address;
Check all images.

Expected behavior
Images link should update automaticaly with the server IP address.

Screenshots

Your Configuration (please complete the following information):

Exact BookStack Version (Found in settings): 0.29.3
PHP Version: 7.4
Hosting Method (Nginx/Apache/Docker): Apache

Originally created by @1vicente on GitHub (Sep 14, 2020). **Describe the bug** In homolog enviroment when the server change ip address, all images and diagrams (Draw.io) are crashing. Verifying I found some possible reason: - images link not change with actual server ip address. But is necessary investigate a reason of diagrams (draw.io) are crashing too. **Steps To Reproduce** Steps to reproduce the behavior: 1. Create a page; 2. Put in an image; 3. Force to change server IP address; 4. Check all images. **Expected behavior** Images link should update automaticaly with the server IP address. **Screenshots** ![image](https://user-images.githubusercontent.com/13755048/93090772-a352b580-f673-11ea-9650-4ba0f8c258f2.png) **Your Configuration (please complete the following information):** - Exact BookStack Version (Found in settings): 0.29.3 - PHP Version: 7.4 - Hosting Method (Nginx/Apache/Docker): Apache

OVERLORD closed this issue

2026-02-05 02:02:40 +03:00

OVERLORD commented

2026-02-05 02:02:46 +03:00

@cdrfun commented on GitHub (Sep 15, 2020):

You have to execute a command to change the urls. This is documented at https://www.bookstackapp.com/docs/admin/commands/

# Update a URL in the database content of your BookStack instance.
# Searches for <oldUrl> and replaces it with <newUrl>
php artisan bookstack:update-url <oldUrl> <newUrl>
# Example:
php artisan bookstack:update-url http://docs.example.com https://demo.bookstackapp.com

@cdrfun commented on GitHub (Sep 15, 2020): You have to execute a command to change the urls. This is documented at https://www.bookstackapp.com/docs/admin/commands/ ``` # Update a URL in the database content of your BookStack instance. # Searches for <oldUrl> and replaces it with <newUrl> php artisan bookstack:update-url <oldUrl> <newUrl> # Example: php artisan bookstack:update-url http://docs.example.com https://demo.bookstackapp.com ```

OVERLORD commented

2026-02-05 02:02:49 +03:00

@1vicente commented on GitHub (Sep 15, 2020):

Hello.

It works!

Thank you for your help.

@1vicente commented on GitHub (Sep 15, 2020): Hello. It works! Thank you for your help.
